Description
IP66 Waterproof , Can use indoor and outdoor
1.5 Mini size
3MP/5MP HD clear picture
8IR LED + 8pcs white led support colorful night vision
Three Night modes Setting : infrared night vision, Colorful night vision, smart night vision
Two Way Audio: Support DIY Alert Voice and Alarm Bell / Customized new speakers with loud volume
Smart Ai Humanoid detection: mixing line, area, two-way flow detection, for human form, the item triggers no alarm.
Three Night modes Setting : black light full color infrared night vision double light warning.
Support cloud/TF Card storage ( Max 128 GB) , data security is more stable.
Use ICSEE APP
| System | Main Processor | 1/2.7″ CMOS Image Sensor 3MP |
| Operation System | Embedded LINUX OS system | |
| Video | High Definition | 3MP |
| Video Compression | Smart H.265+ | |
| Rotation angle | Horizontal:355° ; vertical: 90° | |
| Auto tracking | Support | |
| Illumination | 0.1LUX/F1.2 | |
| Picture Capture | Support | |
| Video Flip | Support | |
| Audio | Coding standard | G.711 |
| Two-way Audio | Support | |
| Record | Video file size | 4.5GB/Day |
| Record Mode | Manual record, motion detection record, scheduled record, alarm record | |
| Video storage | TF Card/Cloud | |
| Playback | Support | |
| Alarm | Alarm recording,screen shot capture | |
| Network | Network Interface | 1*RJ45 , 10/100M10-100 Base-T, self-adaptable Ethernet port |
| WIFI | 802.11b/g/n | |
| Stream | Dual Stream | |
| Network Protocol | Support TCP/IP,RTSP,ONVIF | |
| Transmission mode | P2P,Smart Cloud Sever | |
| WIFI connection | Scan QR code,Network Cable connection,AP Hotspot connection | |
| Extend | TF Card | Max 128GB TF card |
| Reset | Support | |
| Power supply | Power | DC 12V 1A |
| Power consumption | 10W | |
| Working environment | Suitable place | Home,shop,School,factory |
| Installation mode | Wall mounted | |
| Working Temperature | -10℃－＋55℃ | |
| Working humidity | 10%－90% | |
| Other | Camera lens | 3.6MM |
| LED | 8 pcs |
