Description
* Resolution: 2MP/2.5K/4K
* Case: PC special Plastic Housing * Dual Lights: 6 white light+2pcs Array LEDs;
* PTZ rotates: 270° Horizontally and 90° Vertically;
* Smart Ai Humanoid detection
* Support DIY Alert Voice and Alarm Bell
* Support horizontal Direction Auto Tracking;
* Three Night modes Setting:blacklight full-color, infrared night vision, double light warning;
* Support WiFi 2.4Ghz, AP Direct Connection, Wireless Connection, Wired Connection;
* Support Amazon Alex/Echo Show; * Specially customized 5DB UANT antenna;
* Support 5 times magnification, just 5x digital zoom
* Support 128G memory card, support cloud storage
| Model | BK-PT01D2M 【2MP】 | BK-PT01D2K【2.5K】 |
| master control | Dual-core 32-bit DSP (XM530V200） | Dual-core 32-bit DSP (GK7205V210) |
| sensor | 2 million 1/2.8 inch high-performance CMOS sensor | High-performance CMOS sensor |
| Minimum illumination | Color：0.01Lux @(F1.2,AGC ON); 0 Lux with IR； black and white：0.001 Lux @ (F1.2,AGC ON),0 Lux with IR |
|
| shutter | 1/50 (1/60) second to 1/10000 second | |
| focal distance | F2.0*3.6MM | F2.0*3.6MM |
| noise reduction | 支持2D/3D降噪 | |
| Video format | H.265AI | |
| resolving power | Main code stream: 1920 * 1080; Sub-stream: 800 * 448 | Main code stream: 2560 * 1440; Sub-stream: 800 * 448 |
| Frame rate | 12 fps | |
| Intelligent analysis | Support human shape detection | |
| Tracking function | Support human shape zoom tracking | |
| light source | 6 infrared+6 white light | |
| Light mode | Starlight full color/infrared night vision/dual light warning | |
| Two-way voice | sustain | |
| Cloud storage | sustain | |
| Support Agreement | Support NETIP protocol and onvif protocol | |
| network interface | 10M/100M adaptive Ethernet port | |
| Storage interface | Local TF card (up to 256G) | |
| Reset key interface | Support one-click recovery | |
| Wireless standard | IEEE802.11b, 802.11g, 802.11n | |
| frequency range | 2.4 GHz ~ 2.4835 GHz | |
| power waste | 9W | |
| Product size | ||
| Color box size | 145*175*143mm | |
| temperature | Zero 10 ° C -60 ° C, humidity less than 90% [no condensation] | |
| Power Supply | DC 12V ± 10% | |
